Product Parameters | ||||
Project | Name | Specifications | ||
Enter | DC input | DC5521 20V5A Adapter | ||
solar input | DC5521 18-30V/1-5A Solar Panels | |||
car charger input | DC5521 18-30V/1-5A Car Charging | |||
AC output 220V or 110V | AC output voltage | AC220V+ 10% or AC110V + 10% (this is an optional function) | ||
AC output power rating | 300W | |||
AC output peak power | 500W | |||
AC output over rated power protection | 300W | |||
AC output waveform | pure sine wave | |||
frequency | 50Hz/60Hz | |||
USB output port | USB1 output | QC3.0 5V/3A,9V/2A,12V/1.5A-18W(Max) | ||
USB2 output | QC3.0 5V/3A,9V/2A,12V/1.5A- 18W(Max) | |||
TYPE-C1 output | PD 5V/3A,9V/2A,12V/1.5A-18W(Max) | |||
TYPE-C2 output | PD 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A, PD60W(Max) | |||
DC12V output | DC1 DC2 / Cigarette lighter output | 12V/13A- 150W(Max) | ||
LED lights | 1W | Two levels of dimming lighting, SOS flash mode | ||
Batteries | type | Automobile power lithium battery 18650 cylindrical battery | ||
Cell capacity | 2600mAh/3.7V total capacity 124800mAh | |||
Battery pack power | 27Ah/11.1V (300Wh) 3S10P | |||
cycle life | More than 1000 times | |||
charging time | Power Adapter | DC 20V/5A . | ||
Charge from 0% to 100% (automatic cut-off) | 8-10h | |||
Voltage when the battery is fully charged | 12.6V+0.1V | |||
LCD display information | Display power, charging, power failure charging status | Battery percentage and battery column display | ||
DC, AC, inverter status | The display shows | |||
Boot static loss | < 10W | |||
Protective function | safety protection | Short circuit, overload, over temperature, over voltage, over current, under voltage, etc. | ||
over temperature protection | ≥85°C | |||
over temperature recovery | ≤70°C |
